DESCRIPTION | Hold Down Clamp |
---|---|
MODEL NUMBER | TJ28400 |
MEASUREMENTS A | 79mm (Locking Screw Travel ) |
MEASURMENT B | 300mm (Horizontal Bar Travel) |
MEASUREMENT C | 400mm (Vertice Bar Length) |
HORIZONTAL BAR TRAVEL | 40-180mm ( Throat Travel ) |
MAXIMUM LOAD | 2.5kN |
WEIGHT NETT/GROSS | 1.99/ 2.01kg |
VOLUME | 0.0058cm |
Description
SKU : WLT20001214
Price per Unit
$76.00 (Exc GST)
$87.40 (Inc GST)
FEATURES:
* TJ series 90 ° pipe clamp, make accurate powerful clamping 180 ° possible *
* Horizontal bar can adjust the range of 40-180mm, the vertical bar has different
length specifications, and the adjustment range is also different *
* The vertical tube increases the adjusting ring, which can help the adjustment better *
Weight | 1.99 kg |
---|---|
Dimensions | 0.4 × 0.12 × 0.12 cm |
