LATHES TEACH CNC

SWING OVER BED 440mm SWING OVER XSLIDE 235mm DISTANCE BETWEEN CENTRES 1000mm SPEEDS 30-2000RPM SPINDLE BORE 86.0mm SPINDLE NOSE D1-8

SWING OVER BED 440mm SWING OVER XSLIDE 240mm DISTANCE BETWEEN CENTRES 900mm SPEEDS 50-2500Rmm SPINDLE BORE 55.0mm SPINDLE NOSE D1-6

SWING OVER BED 460mm SWING OVER XSLIDE 230mm DISTANCE BETWEEN CENTRES 1000mm SPEEDS 33-3100rpm SPINDLE BORE 56.0MM SPINDLE NOSE D1-6

SWING OVER BED 630mm SWING OVER X SLIDE 400mm DISTANCE BETWEEN CENTRES 1500mm SPEEDS 20-1500Rmm SPINDLE BORE 85/105mm Opt SPINDLE

SWING OVER BED 630mm SWING OVER X SLIDE 400mm DISTANCE BETWEEN CENTRES 2000mm SPEEDS 10-800rpm SPINDLE BORE 85MM 105/155mm Optional

SWING OVER BED 770mm SWING OVER X SLIDE 500mm DISTANCE BETWEEN CENTRES 4100mm SPEEDS 10-800rpm SPINDLE BORE 105/155 Optional SPINDLE

Conversational Programming Fully Inclosed Guarding

Conversational Programming Fully Inclosed Guarding

Conversational Programming Fully Inclosed Guarding

Conversational Programming Fully Inclosed Guarding

Conversational Programming Fully Inclosed Guarding

Conversational Programming Fully Inclosed Guarding

Conversational Programming Fully Inclosed Guarding

SWING OVER BED SWING OVER XSLIDE DISTANCE BETWEEN CENTRES SPEEDS SPINDLE BORE SPINDLE NOSE BAR CAPACITY ZTRAVEL XTRAVEL TOOL POST

* This 2060ENC teach lathe is of rigid construction with hardened & ground beds over HRC 50 * The main spindle is supported by selected and preloaded super precision bearings to ensure high accuracy through full speed range * The main spindle shafts & gears are made from high grade alloy steel which are hardened and precision ground * Automatic lubrication pump provides all slide-ways and two axes ballscrews continuous lubrication at all times * The Fagor 8055TC is user friendly and comes complete with digital SERCOS AC servo system * Features 11 colour monitor * Comes with 8 station turret.

SWING OVER BED SWING OVER XSLIDE DISTANCE BETWEEN CENTRES SPEEDS SPINDLE BORE SPINDLE NOSE BAR CAPACITY ZTRAVEL XTRAVEL TOOL POST

* This Jaguar model teach lathe comes with Fagor 8040TC controller for CNC functions but simple to use * Spindle is supported by selected and preloaded super precision bearings to ensure high accuracy through the full speed range * The main spindle shaft and gears in the headstock are made from high grade alloy steel hardened and precision ground for high speed running and lower noise level * The automatic lubrication pump on the apron provides all slideways and two axes ballscrews lubrication continually * Comes with full length rear splash guard *

Fagor 8055 Control Front Mounted 8 Position Electric Turret Fully Enclosed Guarding Extra Handwheel

SWING OVER BED SWING OVER XSLIDE DISTANCE BETWEEN CENTRES SPEEDS SPINDLE BORE SPINDLE NOSE BAR CAPACITY ZTRAVEL XTRAVEL TOOL POST

* This Jaguar model teach lathe comes with Fagor 8040TC controller for CNC functions but simple to use * Spindle is supported by selected and preloaded super precision bearings to ensure high accuracy through the full speed range * The main spindle shaft and gears are made from high grade alloy steel hardened and ground for high speed running and lower noise level * The automatic lubrication pump on the apron provides all slideways and two axis ballscrews lubrication continually * Comes with full length splash guard *

Fagor 8055TC control LCD monitor. *Over head control console travels with sliding door. *One piece cast base made of high tensile cast iron.* 3 V bed ways hardened and ground for higher rigidity. *Z axis travel matches with centre distance. *Heavy duty tailstock with 2 steps feed. Headstock gears are molybdenum steel SCm21 hardened and precision ground for smooth running. *X & Z axis ball screws are C5 grade. *Repeatability accuracy +/-0.005mm. *Positioning accuracy +/-0.01mm. * Constant surface speed. *Automatic home searching

SWING OVER BED SWING OVER XSLIDE DISTANCE BETWEEN CENTRES SPEEDS SPINDLE BORE SPINDLE NOSE BAR CAPACITY ZTRAVEL XTRAVEL TOOL POST
