TURNING TOOLS-INDEXABLE
LATHE TOOL HOLDER: SVXCR 2525-M13 25.0 X 25.0MM
SKU:
LTH700230
LATHE TOOL HOLDER: SDNCN 1616-H11 16.0 X 16.0MM
SKU:
LTH600910
Characteristics: * Multipurpose profiling toolholder equipped with rhombic positive insert (angle 55 degrees) * The centre screw ensures good rigidity and chip flow * Applications: * External turning and profiling toolholder for general applications, roughing, semi-finishing and finishing * Negative insertss toolholders Ref. PDNN *
LATHE TOOL HOLDER: MTENN 5032-S22
SKU:
LTH610115
Characteristics: * Profiling toolholder with triangular negative double side insert (angle 60 Degrees) with strong cutting edge * The clamp fixing ensures good rigidity and stability in roughing applications*
Applications: * Profiling toolholder for general applications, roughing semi-finishing and finishing *
LATHE TOOL HOLDER: DWLM2 2020-KO6
SKU:
LTH610183
Characteristics: * Multipurpose toolholder equipped with the trigon negative double side insert (angle 80 degrees) with stong cutting edge * The dimple lock ensures good rigidity and chip flow in roughing applications *
Applications: * External turning toolholder for general applications, roughing, semi-finishing and finishing *
*Top clamp toolholder Ref MWLN or MWLN-K *
LATHE TOOL HOLDER: STJCR 1010-E09 10.0 X 10.0MM
SKU:
LTH610212
Characteristics: * Toolholder for external and face turning applications equipped with triangular positive inserts * The centre screw ensures good rigidity and chip flow *
Applications: * External and face turning and toolholder for all kind of materials * The workpiece should be stable * Negative inserts toolholders Ref MTJN-K or MTJN *
LATHE TOOL HOLDER: PWLNR 225-K06 25 X 25MM
SKU:
LTH700554
LATHE TOOL HOLDER: STGCR 0808-F11 8.0 X 8.0MM
SKU:
LTH700624
LATHE TOOL HOLDER: STGCL 2020 K-16 20.0 X 20.0MM
SKU:
LTH700682
LATHE TOOL HOLDER: MWLNL 2525-M06
SKU:
LTH610136
LATHE TOOL HOLDER: PSSNL 2525K-M12 HARTINGEN
SKU:
LTH610154L
Characteristics: * Toolholder for external turning and chamfering applications equipped with square negative inserts and strong cutting edges *
Applications: * External turning and chamfering toolholder for general applications, roughing, semi-finishing and finishing * for Low powered machines and small pieces choose toolholder Ref CSSP *
LATHE TOOL HOLDER: 12.0MM SHANK R/HAND CANALA
SKU:
LTH624070
Characteristics: * Toolholder for external turning applications equipped with trangular positive inserts and strong cutting edges. The top clamp ensures good rigidity and stability.
Applications: * External turning toolholder fo all kind of materials * The workpiece should be stable * For interrupted cut choose toolholder REF PTGN *
LATHE TOOL HOLDER: SVVCN 1212-F11 12.0 X 12.0MM
SKU:
LTH700250
LATHE TOOL HOLDER: CTFPR 2020-K16
SKU:
LTH610100
Characteristics: * Toolholder for face turning applications equipped with triangular positive inserts and strong cutting edges * The top clamp ensures good rigidity and stability*
Applications: * Face turning toolholder for all kind of materials * The workpiece should be stable * For interrupted cut choose toolholder PTFN *
LATHE TOOL HOLDER: MTENN 2020K16-N
SKU:
LTH610116
Characteristics: * Profiling toolholder with triangular negative double side insert (angle 60 Degrees) with strong cutting edge * The clamp fixing ensures good rigidity and stability in roughing applications*
Applications: * Profiling toolholder for general applications, roughing semi-finishing and finishing *
LATHE TOOL HOLDER: SCLCR 2020-K09
SKU:
LTH610184
Characteristics: * Multipurpose toolholder equipped with rhombic positive insert (angle 80 degrees) * The centre screw ensures good rigidity and chip flow *
Applications: * External turning toolholder for general applications, roughing, semi-finishing and finishing * Negative inserts toolholders Ref MCLN-K or MCLN or PCLN *
LATHE TOOL HOLDER: STJCR 1616-H11 16.0 X 16.0MM
SKU:
LTH610216
Characteristics: * Toolholder for external and face turning applications equipped with triangular positive inserts * The centre screw ensures good rigidity and chip flow *
Applications: * External and face turning and toolholder for all kind of materials * The workpiece should be stable * Negative inserts toolholders Ref MTJN-K or MTJN *
LATHE TOOL HOLDER: SCLCR 2020-K09 20 X 20MM
SKU:
LTH700560
LATHE TOOL HOLDER: STGCR 1010-F11 10.0 X 10.0MM
SKU:
LTH700626
LATHE TOOL HOLDER: STGCL 2525 M16 CANELA 25.0 X 25.0MM
SKU:
LTH700684
LATHE TOOL HOLDER: MWLNR 1616-H06
SKU:
LTH610140
Characteristics: * Multipurpose toolholder equipped with trigon negative double side insert (angle 80 Degrees) with strong cutting edge * The centre pin and top clamp ensure good rigidity and stability in roughing applications *
Applications: * External turning toolholder for general applications, roughing, semi roughing, semi-finishing and finishing * Not suitable for cermet, ceramic and K10, P10 grade inserts *
LATHE TOOL HOLDER: SCLCL 1010-E06
SKU:
LTH610156
Characteristics: * Multipurpose toolholder equipped with rhombic positive insert (angle 80 degrees) * The centre screw ensures good rigidity and chip flow *
Applications: * External turning toolholder for general applications, roughing, semi-finishing and finishing * Negative inserts toolholders Ref MCLN-K or MCLN or PCLN *
LATHE TOOL HOLDER: 16.0MM SHANK L/HAND CANELA
SKU:
LTH624090
Characteristics: * Toolholder for external turning applications equipped with trangular positive inserts and strong cutting edges. The top clamp ensures good rigidity and stability.
Applications: * External turning toolholder fo all kind of materials * The workpiece should be stable * For interrupted cut choose toolholder REF PTGN *
LATHE TOOL HOLDER: MTJNL 1616-H16 16.0 X 16.0MM
SKU:
LTH624502
LATHE TOOL HOLDER: PRDCN 2525-M12 25.0 X 25.0MM
SKU:
LTH700138
LATHE TOOL HOLDER: SVVCN 1616-H11 16.0 X 16.0MM
SKU:
LTH700255
LATHE TOOL HOLDER: CTFPR 2525-M16 25.0 X 25.0MM
SKU:
LTH610104
Characteristics: * Toolholder for face turning applications equipped with triangular positive inserts and strong cutting edges * The top clamp ensures good rigidity and stability*
Applications: * Face turning toolholder for all kind of materials * The workpiece should be stable * For interrupted cut choose toolholder PTFN *
LATHE TOOL HOLDER: MTENN 2525M16-N
SKU:
LTH610120
Characteristics: * Profiling toolholder with triangular negative double side insert (angle 60 Degrees) with strong cutting edge * The clamp fixing ensures good rigidity and stability in roughing applications*
Applications: * Profiling toolholder for general applications, roughing semi-finishing and finishing *
LATHE TOOL HOLDER: SCLCR 2525-H09
SKU:
LTH610185
Characteristics: * Multipurpose toolholder equipped with rhombic positive insert (angle 80 degrees) * The centre screw ensures good rigidity and chip flow *
Applications: * External turning toolholder for general applications, roughing, semi-finishing and finishing * Negative inserts toolholders Ref MCLN-K or MCLN or PCLN * This is a right hand lathe toolholder and takes CCMT09T3 inserts *
LATHE TOOL HOLDER: MTJNL 2020-K16 20.0 X 20.0MM
SKU:
LTH624506
Characteristics: * Turning and profiling equipped with triangular negative double side insert with strong cutting edge * The centre pin and top clamp ensure good rigidity and stability in roughing applications *
Applications: * External turning and profiling toolholder for general applications, roughing, semi-finishing and finishing * Specially recommended for cermet, ceramic and K10, P10 grade inserts *
*For low powered machines and small pieces choose toolholder Ref STJC
LATHE TOOL HOLDER: SCLCR 0808 8 X 8MM
SKU:
LTH700570
.LATHE TOOL HOLDER: STGCR 1212-F11 12.0 X 12.0MM
SKU:
LTH700630
LATHE TOOL HOLDER: CTGPR 2525-M16 EXT 25.0 X 25.0MM
SKU:
LTH700130
