The ideal punching machine to enter the world of punching, at an affordable price. It is the evolution of Tecnumerik in fact it has the same CNC functions as an automatic machine. The rotating head allow the orientation of any type of tool, as well as the use of multi-tools, drag tools for cutting, ribs, off-set, and tapping tool. Innovative vertical turret The strategic position of the Vertical Turret enables more complex forming operations to be carried out, thanks to the reduced encumbrance in the work area. Moreover, the operator has a better visibility of the sheet metal being worked. Maximum configuration versatility The machine configuration can be customized by inserting any kind of tool in every station. The innovative Speedy Setup system allows to equip each station in just 12 seconds. All tools are rotating (auto-index) By rotating any tool from 0° to 360° the number of tools to be purchased and the machining time is significantly reduced. Sheet metal waste is minimized thanks to the possibility of performing complex nestings. Latest servo drive technolgy with FANUC motor and FANUC Controller. Compatibility with Trumpf tools

TECHNOLOGY turrets are equipped with the thick turret tool change system, with a holding capacity of up to 48 tools, including 4 stations with 0° to 360° rotation (auto-index). The turret of TECHNOLOGY punching machines is one of the highest on the market. This guarantees the best processing quality and maximum tool life, thanks to the possibility of guiding the punch with greater stability. It has 40 tool stations, 2 of which are auto-index. SoftPunch mode. This function allows to considerably reduce the noise when machining thicker workpieces. Absence of hydraulic oil. Reduction in energy consumption and disposal costs due to the absence of hydraulic oil Less maintenance costs: With fewer components in an electrical system that are exposed to wear and tear, maintenance costs can be significantly reduced. Stand-by mode. During stand-by mode the motors are switched off to reduce power consumption to only 0.4 Kw Compatibility with Trumpf tools

Ideal for large-scale production for companies seeking a high level of technology and performance. One of a kind in terms of accessibility and versatility. The reduced dimensions of the vertical turret in the working area allows the machining of corrugated sheets or sheets with thicknesses up to 4/6mm. It can be equipped with an automatic loading and unloading system for sheet metal, allowing a nonstop production. SERVO DRIVE PUNCHING UNIT: FANUC high-performance servo drive punching unit without any hydraulic oil, ensuring low energy consumption. It also includes DualCam technology for high frequency machining operations avoiding overheating of the motor VERTICAL TURRET: Groundbreaking 15-stations tool change system, unique on the market thanks to its vertical design. This feature, worldwide patented by TECHNOLOGY, allows to have the smallest possible encumbrance in the working area. It can be set up in few seconds thanks to the Speedy Setup system. “C” FRAME: It enables you to process sheets that are bigger than the machine's working range and to load them both frontally and sideways. The open "C" frame ensures the operator the highest accessibility and visibility of the working area. INTEGRATED AUTO-INDEX SYSTEM: It enables to rotate any tool from 0° to 360° DUAL MOTOR ON Y-AXIS: The TP Zeta is equipped with a dual motor for Y-axis movement that takes performances to the next level. TP Zeta can reach a punching frequency of 900 strokes/min Compatibility with Trumpf tools

MODEL VT-300 DESCRIPTION “A” Station Thick Turret TO SUIT VT-300 SIZE 6.8mm Round WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “A” Station Thick Turret TO SUIT VT-300 SIZE 8.0mm Round WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “C” Station Thick Turret TO SUIT VT-300 SIZE 50.0mm Round WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “D” Station Thick Turret TO SUIT VT-300 SIZE 61.50mm Round WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “D” Station Thick Turret TO SUIT VT-300 SIZE 40.0mm Square WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “B” Station Thick Turret TO SUIT VT-300 SIZE 15 x 5 x R2.5 OBLONG WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “D” Station Thick Turret TO SUIT VT-300 SIZE 40 x 5mm Rect WEIGHT VOLUME

MODEL VT-300 DESCRIPTION “D” Station Thick Turret TO SUIT VT-300 SIZE 50 x 5mm Rect WEIGHT VOLUME
