HYDRAULIC GUILLOTINE: CNC 12MM X 3200MM VARIABLE RAKE
$65,200.00
| Weight | 12000 kg |
|---|---|
| Dimensions | 4 × 1.85 × 2.4 cm |
Description
| MODEL | QC11Y 12 X 3200 |
|---|---|
| CONTROLLER | Delem DAC360T |
| SHEARING CAPACITY | 12.0mm Mild Steel |
| BLADE LENGTH | 3200mm |
| RAKE ANGLE VARIABLE | Yes |
| MAX RAKE ANGLE | 2.5 degree |
| MIN RAKE ANGLE | 1 Degree |
| NO HOLDDOWN | 12Pcs |
| HOLDING FORCE | 30 Psi |
| BACK GAUGE TRAVEL | 1000mm |
| MOTOR | 18.5 Kw |
| LENGTH | 3900mm |
| WIDTH | 1900mm |
| HEIGHT | 2250mm |
| WEIGHT NETT/GROSS | 1,2000kg |
| VOLUME | 17.760cm |
| PACKING SIZE L x W x H | 4000 x 1850 x 2400mm |
Shipping & Delivery
Related products
HYDRAULIC GUILLOTINE: BENZEL 6MM X 2500MM
SKU:
SRH132213
* Blade gap adjusting dial mounted on side of machine for convenient and accurate alteration for all your material thickness from 0.5 - 4mm.
* This dial is designed so that a straightforward rotation clock or anti clockwise to achieve desired plate thickness.
* Measurement on dial indicates and refers to actual blade gap distance in millimetres.
* CONTROLLER ESTUN E21S.
* Control unit mounted on swivel pendant arm. Transfer balls inserted into work table allowing material to be easily moved.
HYDRAULIC GUILLOTINE: HSH 4MM x 2500MM VARIABLE RAKE
SKU:
SRH132215
* This Benzel 4.0mm x L2500mm guillotine is the variable rake type
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with the Estun E-245 controller for easy and effective cutting control
* Fitted with photo sensor protection at the rear of this machine *
HYDRAULIC GUILLOTINE: BENZEL 6MM X 3200MM
SKU:
SRH132223
* This Benzel 6.0mm x L3200mm swing beam type
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with Estun E-245 controller for easy effective cutting control
* Fitted with photo sensor protection at the rear of this machine
HYDRAULIC GUILLOTINE: BENZEL 6MM X 4200MM Swing Beam
SKU:
SRH132224
* This Benzel 6.0mm x L4200mm guillotine is a Swing Beam type
* Fixed Rake 1.5 degs.
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with the Estun E-10S controller for easy and effective cutting
* Fitted with photo sensor protection at the rear of this machine
HYDRAULIC GUILLOTINE: BENZEL 8MM X 3200MM Swing Beam
SKU:
SRH132225
HYDRAULIC GUILLOTINE: HSH 12MM X 3200MM VARIABLE RAKE
SKU:
SRH132227
HYDRAULIC GUILLOTINE: BENZEL 10MM X 3200MM
SKU:
SRH132228
HYDRAULIC GUILLOTINE: HSH 20MM X 3200MM VARIABLE RAKE
SKU:
SRH132236
