MODEL | BENZEL-4.0 X 2500mm |
---|---|
CONTROLLER | Estun E21-S with Invertor |
SHEARING CAPACITY | 4.0mm Mild Steel |
BLADE LENGTH | 2500mm |
RAKE ANGLE VARIABLE | No |
MAX RAKE ANGLE | No |
MIN RAKE ANGLE | No |
HOLDDOWN CLAMPS | 9pcs |
OIL CAPACITY | 170 L |
BACK GAUGE | 20.0mm To 900mm with Ball screw. |
MOTOR | 5.5kw |
LENGTH | 3130mm |
WIDTH | 2030mm |
HEIGHT | 1600mm |
WEIGHT NETT/GROSS | 3800/ 4000kg |
VOLUME | 15.972cm |
PACKING SIZE L X W X H | 3300 x 2200 x 2200mm |
“QUICK CHANGE TOOL HOLDERS: MIX” has been added to your cart. Continue shopping
Sold out
Availability : Enquire Now
Price per Unit
ex-gst
$19,800.00Inc-gst
$22,770.00HYDRAULIC GUILLOTINE: BENZEL 4MM X 2500MM
Description
SKU : SRH132211
Price per Unit
$19,800.00 (Exc GST)
$22,770.00 (Inc GST)
FEATURES:
* Blade gap adjusting dial mounted on side of machine for convenient and accurate alteration for all your material thickness from 0.5 – 4mm
* This dial is designed so that a straightforward rotation clock or anti clockwise to achieve desired plate thickness
* Measurement on dial indicates and refers to actual blade gap distance in millimetres
* Controller: Estun E21S. Control unit mounted on swivel pendant arm
* Transfer balls inserted into work table allowing material to be easily moved
Weight | 4000 kg |
---|---|
Dimensions | 3.3 × 2.2 × 2.2 cm |
Specifications
Description
Reviews (0)
Be the first to review “HYDRAULIC GUILLOTINE: BENZEL 4MM X 2500MM” Cancel reply
Shipping & Delivery
Related products
HYDRAULIC GUILLOTINE: BENZEL 6MM X 2500MM
