CNC LATHE: RICHYOUNG RIC-TC33200 TEACH
$0.00
Conversational Programming Fully Inclosed Guarding
| Weight | 6180 kg |
|---|---|
| Dimensions | 5.5 × 2.25 × 2.45 cm |
Description
| SWING OVER BED | 840mm |
|---|---|
| SWING OVER X SLIDE | 570mm |
| DISTANCE BETWEEN CENTRES | 5100mm |
| SPEEDS | 5-350rpm |
| SPINDLE BORE Options) | 80, 105, 155, 230, 305mm |
| SPINDLE NOSE | A-11 |
| BAR CAPACITY | 100mm |
| Z TRAVEL | 3000mm |
| X TRAVEL | 450mm |
| TOOL POST | 8 Position Turret or QCT |
| SPINDLE MOTOR | 11.6kw |
| TAILSTOCKTAPER | MT5 |
| CONTROLLER | FAGOR, SEIMEMS 808D,828D, FANUC. |
| WEIGHT NETT/GROSS | 6180/5600kg |
| VOLUME | 30.3188cm |
| FLOOR SPACE | L5500 x W2250 x H2450mm |
