GRINDING WHEEL: 255 X 32 X 31.75MM A36
Excl. GST: $117.40
Incl. GST: $135.01
Incl. GST: $135.01
SAW BLADE: TCT 210 X 60T SSC WALLSAW
Excl. GST: $121.54
Incl. GST: $139.77
Incl. GST: $139.77
RADIAL DRILL: Z3050 1600MM
Excl. GST: $16,053.00
Incl. GST: $18,460.95
* The Radial drilling machines are widely used for drilling counterboring reaming facing Tapping even boring when equipped with a special device * The spindle head radial arm and columns clamped by band mechanisms * The reversing and feeding changes are wide and the control keys are all compact reliable and convenient * Supplied with box table which has slotted ways for attaching clamping devices *
| Weight | 4000 kg |
|---|
Description
| MODEL | Z3050-16/1 |
|---|---|
| DRILLING CAPACITY | 50.0mm |
| SPINDLE TRAVEL | 315mm |
| SPINDLE TAPER | No.5 |
| SPINDLE SPEEDS | 16 |
| RANGE OF SPEEDS | 25-2000rpm |
| COLUMN DIAMETER | 350mm |
| NOSE TO COLUMN | 1600mm |
| BASE TO SPINDLE | 1220mm |
| MAIN MOTOR | 4kw |
| ARM LIFT MOTOR | 1hp |
| WEIGHT NETT/GROSS | 3500/4000kg |
| VOLUME | 7.950cm |
Shipping & Delivery
Related products
RADIAL DRILL: RSB-20A BENCH
SKU:
RD-355120
* This is an industrial quality drilling machine and is an ideal machine when drilling large workpieces * Outstanding features of include: longitudinal travel of the drill head of 450mm the head can be swiveled 360deg head can be tilted for angled drilling * The large table on this machine measures 460x450mm * This model comes without stand *
RADIAL DRILL: RSB-20B W/STAND
SKU:
RD-355130
* This is an industrial quality drilling machine and is an ideal machine when drilling large workpieces * Outstanding features of include: longitudinal travel of the drill head of 450mm the head can be swiveled 360deg head can be tilted for angled drilling * The large table on this machine measures 460x450mm * This model comes without stand *
RADIAL DRILL: RDC-32700 MT3
SKU:
RD-355150
RADIAL DRILL: TF-900S TAIWAN
SKU:
RD-355239
RADIAL DRILL: 1000 Z3032 X 10/1
SKU:
RD-355300
* Main parts and key parts are made by high strength cast and special steel material
* Adopting hydraulic pre-selection speed and feed change mechanisms and is sensitive and reliable
* Machanical and electrical controls are centralized on the headstock
* with easy and rapid operation
* The main ways are all case-hardned so as to prolong the service life of the machine
RADIAL DRILL: 1600 Z3050 x 16/1
SKU:
RD-355395
* The Radial Drilling machines are widely used for Drilling, Tapping, Counterboring, Reaming, Boring and others.
* The Z-Series Radial Drill has been developed and manufactured for over 58 years in one of the largest production facilities in the world
* It has a unique Hydraulic variable frequency motor that allows a stepless regulation of the spindle speeds including Forward/Reverse & Stop using one control lever.
RADIAL DRILL: Z1600EVS X 1600MM SERVO VARIABLE SPEED
SKU:
RD-355410
* This new Z5016EVS Radial Drilling machines are now available
* Uses include drilling, Tapping, Counterboring, Reaming, Boring etc
* The Z-Series Radial Drill has been developed and manufactured for over 58 years in one of the largest production facilities in the world
* It has a unique Hydraulic variable frequency motor that allows a stepless regulation of the spindle speeds including Forward/Reverse & Stop using one control lever
* Features include the new digital touch screen display panel
BOX TABLE: 550 X 405 X 315MM
SKU:
RD-355600
