* Excellent chip control even when machining with a small depth of cut
* Suitable for machining with a variable depth of cut.Proper rake angle of cutting surface finish and low cutting resistance
* The MT-TiCN inner Coated is hard and wear-resisant against abrasive wear
* Techical Features (PHG) for high wear resistance and long life

Weight	0.001 kg
Dimensions	0.1 × 0.03 × 0.03 cm

Compare

Add to wishlist

Specifications

Description

BRAND	PALBIT (EUROPE) SINCE 100YEARS
MODEL	GCMX-4N
SIZE	W =4,1 B = 3,5 Re = 0,25
BEST FOR	Parting and Grooving
SUIT TO	LTP820006
COATINGS	TOP COATING (TIN) CVD- ALUMINA COATING
HEAT- RESISTANT SUBSTRADE	The cemented-carbide substrate adds high strength for application with focus on high material rmoval
APPLICATION	Wet and Dry Machining, External & Internal Turning. Roughing to finishing.
WEIGHT NETT/GROSS	0.0010kg
VOLUME	0.0001cm
