MILLING MACHINE: V2 1224 X 228MM TABLE NT40 1PH TURRET
$9,800.00
* This 2V model is the smallest of the Turret milling machines made in China
* Fitted with Tawann milling head which icorperates P5 spindle bearings
Comes with E-GEO lead screws for utmost accuracy
* Fitted with 2 axis DRO
* Comes as a manual machine but you can add power feeds etc onto it
* Y-Z axes rubber way covers.
* Auto lubrication system.
* Electrical cabinet
* Shindle taper is NT40
Overhead pentant control panel for convenient
| Weight | 1250 kg |
|---|---|
| Dimensions | 1.54 × 1.435 × 2.06 cm |
Description
| Table Size (mm) | 1224 x 228 |
|---|---|
| Travel X-axis (mm) | 762 |
| Travel Y-axis (mm) | 337 |
| Travel Z-axis (mm) | 406 |
| Quill Stroke (mm) | 127 |
| Quill Diameter (mm) | 85 |
| Spindle Taper | NT40 |
| Speeds (no.) | 3 steps |
| Speed Range (rpm) | 60 – 4200 |
| Motor (kW) | 2.25 1 Phase |
| Weight (kg) | 1250 |
| Volume | 4.5524cm |
| Packing Size L x W x H (mm) | 1540 x 1435 x 2060 |
Shipping & Delivery
Related products
MILLING MACHINE: GLOBAL WM20 1PH
SKU:
MM-228100
MILLING MACHINE: X6325D /TM240 NT40 1 PH (BALL SCREWS)
SKU:
MM-228510
* The TM-240 (X6323B) is a turret style milling machine.
* Fully tiliting, swivelling & rotating head.
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle.
* Double 55° dovetail guide way is adopted on both Y and Z axis.
* One shot lubrication.
MILLING MACHINE: TM240A (X6325A) NT30 (BALL SCREWS)
SKU:
MM-228512
* The TM-240A (X6325A) is a turret style milling machine.
* Fully tiliting, swivelling & rotating head.
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle.
* Double 55° dovetail guide way is adopted on both Y and Z axis.
* One shot lubrication.
MILLING MACHINE: TM270 (M6325D) TURRET 3PH NT40
SKU:
MM-228615
* The TM-270 (X6325D) is a turret style milling machine.
* Head is fully tiliting, swivelling & rotating
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle
* Variable speed from 65-4500rpm
* Double 55° dovetail guide way is adopted on both Y and Z axis.
* One shot lubrication
* Comes with power rise and fall on X axis
* X & Y axis are fitted with aglin power feeds (Taiwan)
Digital 3 axis readout is Sino brand
MILLING MACHINE: 4H 1270 X 254MM TABLE TURRET TAIWAN
SKU:
MM-244128
MILLING MACHINE: 6H 1372 X 254MM TABLE TURRET TAIWAN
SKU:
MM-244136
* The 6H model comes with standard 1372mm table length.
* Table is hardened and ground for durability and long service life.
* Powerful 5hp motor.
* Large diameter quill (105mm) for rigid milling performance.
* Y-Z axis rubber way cover.
* Auto lubrication system.
* Electrical cabinet.
* Made in Taiwan.
MILLING MACHINE: 4VS 1370 X 254MM TABLE TURRET TAIWAN
SKU:
MM-244242
* The 4VS model turret milling machine comes with two table options - 1270 & 1370mm.
* Table and guideways are hardened and precision ground.
* Y-Z axis have rubber way cover for protection.
* Auto lubrication system.
* Electrical cabinet.
* One shot lubrication system.
* Ways are X & Y are Tercite B coated.
* Fitted with power feed on X travel.
* Made in Taiwan.
MILLING MACHINE: PBM-GVS300A PHOEBUS TAIWAN
SKU:
MM-280050
* This is a very heavy universal type milling machine with large 1470 x 300mm table.
* Both horizontal and vertical spindle tapers are NT40.
* Vertical head is variable speed while the horizontal spindle has 9 steps.
* Power feed on X, Y and Z direction with rapids.
* Comes with pendant control.
* Equipped with electric box.
* Made in Taiwan.
