TOOL & CUTTER GRINDER: D-Bit Grinder 10A
Excl. GST: $1,900.00
Incl. GST: $2,185.00
Incl. GST: $2,185.00
CT-150C: JC-14 SCREW
Excl. GST: $1.75
Incl. GST: $2.01
Incl. GST: $2.01
LATHE: WM-250GN 250 X 500 X 26MM BORE (NEW MODEL) 1 PH
Excl. GST: $3,900.00
Incl. GST: $4,485.00
* New model, one of our most popular lathes with new modifications.
* Induction hardened & precision ground V-way beds.
* Tailstocks can be offset for turning tapers.
* Stand alone coolant pump & tank system.
* Handy LED lamp located in the middle of splashguard.
* Includes change gears for metric & imperial threading.
* Righthand & lefthand thread cutting is available.
* Spindle supported by high precision bearings.
* Adjustable gibs for slideways.
* Also available with powered cross slide & longitudinal feed.
* Stand is sold seperately.
| Weight | 185 kg |
|---|---|
| Dimensions | 1.2 × 0.6 × 0.65 cm |
In stock
Description
| Swing Over Bed (mm) | 250 |
|---|---|
| Swing Over X-slide (mm) | 135 |
| Swing Over Gap (mm) | N/A |
| Between Centres (mm) | 500 |
| Bed Width (mm) | 140 |
| Spindle Nose | Threaded |
| Speeds (no.) | 12 |
| Speed Range (rpm) | 80 – 1,600 |
| Spindle Bore (mm) | 26 |
| Spindle Taper | MT3 |
| Metric Threading (M) | 0.125 – 5.0 |
| Imperial Threading (tpi) | 4 – 96 |
| Tailstock Taper | MT3 |
| Tool Height (mm) | 12 |
| Motor (kW) | 0.75 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 165 / 185 |
| Volume | 0.4680cm |
| Packing Size L x W x H (mm) | 1,200 x 600 x 650 |
Shipping & Delivery
Related products
LATHE: LD-1430E 360 X 750MM 3PH WITH DRO QCT (TAIWAN)
SKU:
L--109295
* Induction hardened & precision ground V-way beds.
* Hardened & ground headstock gears.
* Cast from quality high tensile cast iron.
* Sino 2 axis digital readout.
* Coolant pump & tank system.
* Fitted with a work lamp & foot brake for added safety.
* Quickchange toolpost for speedy tool changing.
* Dual graduation thread dial.
* Gap bed for larger diameter work pieces.
* Manufactured in Taiwan.
LATHE: WM-330BV 330 X 1000 X 51.0MM BORE V/SPEED 1 PHASE
SKU:
L--120000
* The WM-330BV is variable speed with frequency inverter.
* The D1-5 spindle comes with a 51.0mm bore.
* Comes with gap bed for those larger diameter workpieces.
* Automatic feed and thrading are fully interlocked.
* Inductioned hardened and precision ground V bedways.
* Hardened and precision ground headstock gears.
* Fitted with independent leadscrew and feed shaft
LATHE: WM330 330 X 500 X 38MM BORE -L1320, 1 PHASE
SKU:
L--120466
* Precision ground and supersonic frequency hardened bedways.
* The spindle is supported with precision roller bearings.
* Head stock gears are made of high quality steel ground and hardened.
* Sealed and easy operating feed box has various feeds and thread cutting functions.
* ASA D1-4 camlock spindle nose.
* Machine is fitted with foot brake & work lamp for extra safety.
* Short bed length and space saving for training institutions.
* Fitted with safety chuck guard.
LATHE: WM330 330 X 750 X 38MM 1 PHASE
SKU:
L--120467
* Precision ground and supersonic frequency hardened bedways.
* The spindle is supported with precision roller bearings.
* Head stock gears are made of high quality steel ground and hardened.
* Sealed and easy operating feed box has various feeds and thread cutting functions.
* ASA D1-4 camlock spindle nose.
* Machine is fitted with foot brake & work lamp for extra safety.
* Short bed length and space saving for training institutions.
* Fitted with safety chuck guard.
LATHE: GLH-330 330 X 750 X 38MM 1 PHASE (NEW)
SKU:
L--120468H
* New Model
* Precision ground and supersonic frequency hardened bedways.
* The spindle is supported with precision roller bearings.
* Head stock gears are made of high quality steel ground and hardened.
* Sealed and easy operating feed box has various feeds and thread cutting functions.
* ASA D1-4 camlock spindle nose.
* Machine is fitted with foot brake & work lamp for extra safety.
* Short bed length and space saving for training institutions.
* Fitted with safety chuck guard.
* Emergency stop buttons both ends of chip tray
LATHE: L-320/CQ9332 320 X 600 X 38MM BORE, 1 PHASE
SKU:
L--120502
LATHE: WM-250G 250 X 500 X 26MM BORE 1 PHASE
SKU:
L--165260
* Most economical, widely useful hobby lathe
* Induction hardened & precision ground V-way beds.
* Tailstocks can be offset for turning tapers.
* Large MT4 spindle bore
* New enclosed quick-change gear box
* Precise cuts with cross & longitudinal powerfeed
* Includes change gears for metric & imperial threading.
* Righthand & lefthand thread cutting is available.
* Spindle supported by high precision bearings.
* Adjustable gibs for slideways
* Tailstock can be offset for turning taper.Tolerance test certificate, test flow chart included
* Stand sold seperately
functions. .
LATHE: WM-250V 250 X 750 X 26MM BORE V/SPEED 1 PHASE
SKU:
L--165270
* V-way bed is hardened & precision ground.
* Spindle is supported by a precision tapered roller bearing.
* MT3 spindle taper gets more capacity.
* Powered longitudinal feed for threading.
* Adjustable gibs for slideways.
* Right land & left hand thread cutting is available.
* Tailstock can be offset for taper turning.
* Equipped with high quality gearbox belt & control board.
* Stand is sold seperately.
