LATHE: JESSEY GENERAL 660 X 3000 (TAIWAN)
$0.00
* Rigid construction beds are induction hardened and precision ground.
* Harden and ground spindle & gears in headstock for high speed running with low noise.
* Fitted with magnetic brake, and Matrix clutch system.
* Both axes have rapid power feed fitted for quick positioning.
* Rigid tailstock with two speed quill plus rack and handle positioning.
* Front draw chip tray for easy cleaning.
* One-shot oil pump on saddle provides excellent slideways central lubrication.
* Comprehensive range of metric, imperial, diametral & modular threads.
* Made in Taiwan.
| Weight | 4300 kg |
|---|
Description
| Swing Over Bed (mm) | 660 |
|---|---|
| Swing Over X-slide (mm) | 460 |
| Swing Over Gap (mm) | 860 |
| Between Centres (mm) | 2660 |
| Bed Width (mm) | 480 |
| Spindle Nose | D-1-11 |
| Speeds (no.) | 16 |
| Speed Range (rpm) | 10 – 1395 |
| Spindle Bore (mm) | 105 |
| Spindle Taper | MT8 |
| Metric Threading (M) | 0.2 – 14.0 |
| Imperial Threading (tpi) | 2 – 72 |
| Tailstock Taper | MT6 |
| Motor (kW) | 11.25 |
| Voltage (V) | 415 |
| Weight Nett / Gross (kg) | 3800 / 4300 |
Shipping & Delivery
Related products
LATHE: GOSAN 2060 510 X 1500MM 10HP
SKU:
L--109232
* Heavy duty geared head lathe, with hardened and ground gears.
* 3-point supported spindle using 2 precision taper roller bearings and 1 ball bearing.
* Spray lubrication system used for headstock.
* One shot lubrication pump for cross slide and bed-ways.
* Quick-change universal gearbox for inch, metric, DP and MP threading.
* Adjustable overload clutch in apron ensures proper cutting load.
* Cross slide screw is permanently immersed in oil and supported by thrust bearing.
* One piece base casting for maximum rigidity.
LATHE: GOSAN 2080A 510 X 2000MM 10HP
SKU:
L--109236
* Heavy duty geared head lathe, with hardened and ground gears.
* 3-point supported spindle using 2 precision taper roller bearings and 1 ball bearing.
* Spray lubrication system used for headstock.
* One shot lubrication pump for cross slide and bed-ways.
* Quick-change universal gearbox for inch, metric, DP and MP threading.
* Adjustable overload clutch in apron ensures proper cutting load.
* Cross slide screw is permanently immersed in oil and supported by thrust bearing.
* One piece base casting for maximum rigidity.
LATHE: GL-3040 3000 X 4000M STANDING LATHE
SKU:
L--110180
* This heavy duty standing lathe has a free standing headstock and tailstock.
* Suitable for large workpiecees and can be adjusted to different lengths between centers.
* Has a 3.5m swing over bed.
* Comprised of three main independent components: headstock, apron, and tailstock.
* Features rapid traverse on all axes.
* Supplied with 4 jaw 1600mm chuck.
* 3 Jaw chuck and faceplate are available to suit.
* Steadies are available to suit customers requirements.
LATHE: GL-3040 OPEN SUPPORT STANDING LATHE
SKU:
L--110182
LATHE: L22 GM6256 560 X 1000 X 80MM BORE
SKU:
L--120028
* Precision ground & supersonic frequency hardened bedways, with double wall structure for super rigidity.
* Highly accurate & rigid spindle system.
* Optimized design of the main drive, with hardened & ground headstock gears.
* Fitted with 2 axis digital readout, taper turning attachment & quickchange toolpost.
* Over 200 thread cutting options available, in metric, whitworth, module & DP, with no gear changing required.
* Adjustable auto stop mechanism for longitudinal travel.
* Gap bed for larger diameter work pieces.
LATHE: CWA61100 1000 X 8000 X 105MM BORE
SKU:
L--120156
* This CWA61100 lathe offers precision ground & supersonic frequency hardened bedways.
* Double wall structure provides super rigidity and accuracy.
* Extra large 105mm spindle bore.
* Optimised design of the main drive.
* Precision ground headstock gears.
* Machine operation does not require gear changes.
* This lathe can turn up to 200 kinds of metric, whitworth, module & DP threads.
* Auto stop device and footbrake offer quick & effective stopping.
LATHE: C6266C 660 X 2000 X 105MM BORE
SKU:
L--120441
* Supersonic frequency hardened bedways.
* Hardened & ground headstock gears.
* Triple headstock spindle bearings.
* 105mm spindle bore for turning large shafts.
* Fitted with a powerful 9kW motor.
* No gear changing required to cut metric & imperial threads.
* Fitted with Sino 2 axis digital readout, taper turning attachment & quickchange toolpost.
LATHE: C62680EX 800 X 3000 X 105MM BORE
SKU:
L--120456
* Supersonic frequency hardened bedways.
* Hardened & ground headstock gears.
* Triple headstock spindle bearings.
* 105mm spindle bore for turning large shafts.
* Fitted with a powerful 15kw motor.
* No gear changing required to cut metric & imperial threads.
* Fitted with Sino 2 axis digital readout, taper turning attachment & quickchange toolpost.
