| Swing Over Bed (mm) | 800 |
|---|---|
| Swing Over X-slide (mm) | 480 |
| Swing Over Gap (mm) | 1000 |
| Between Centres (mm) | 3,000 |
| Bed Width (mm) | 550 |
| Spindle Nose | D1-11 |
| Speeds (no.) | 18 |
| Speed Range (rpm) | 14 – 750 |
| Spindle Bore (mm) | 105 |
| Spindle Taper | MT6 |
| Metric Threading (M) | 1-240mm/rev (54 Kinds) |
| Imperial Threading (tpi) | 28-1″ (36 kinds |
| Tailstock Taper | MT6 |
| Tool Height (mm) | 20 |
| Motor (kW) | 15 |
| Voltage (V) | 415 |
| Weight Nett / Gross (kg) | |
| Volume (m³) | |
| Packing Size L x W x H (mm) |
Description
SKU : L--120456
Price per Unit
$68,500.00 (Exc GST)
$78,775.00 (Inc GST)
FEATURES:
* Supersonic frequency hardened bedways.
* Hardened & ground headstock gears.
* Triple headstock spindle bearings.
* 105mm spindle bore for turning large shafts.
* Fitted with a powerful 15kw motor.
* No gear changing required to cut metric & imperial threads.
* Fitted with Sino 2 axis digital readout, taper turning attachment & quickchange toolpost.
| Weight | 4500 kg |
|---|
