HYDRAULIC GUILLOTINE: BENZEL 6MM X 4200MM Swing Beam
$39,500.00
* This Benzel 6.0mm x L4200mm guillotine is a Swing Beam type
* Fixed Rake 1.5 degs.
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with the Estun E-10S controller for easy and effective cutting
* Fitted with photo sensor protection at the rear of this machine
| Weight | 8000 kg |
|---|---|
| Dimensions | 5 × 2 × 1.66 cm |
Description
| MODEL | HSH 6.0mm x 4200mm |
|---|---|
| CONTROLLER | Estun E-10S |
| SHEARING CAPACITY | 6.0mm Mild Steel – Swing Beam |
| BLADE LENGTH | 4200mm |
| RAKE ANGLE VARIABLE | N.A. Fixed |
| MAX RAKE ANGLE | 1.5 degs Fixed |
| MIN RAKE ANGLE | N.A. |
| NO HOLDDOWN | 16 |
| HOLDING FORCE | 20 bar |
| BACK GAUGE | 990 mm |
| MOTOR | 7.5 Kw |
| LENGTH | 3840mm |
| WIDTH | 2320mm |
| HEIGHT | 1620mm |
| WEIGHT NETT/GROSS | 7,900/ 8,000kg |
| VOLUME | 17,340cm |
| PACKING SIZE L x W x H | 5100 x 2000 x 1660mm |
