HYDRAULIC GUILLOTINE: BENZEL 6MM X 2500MM
$28,200.00
* Blade gap adjusting dial mounted on side of machine for convenient and accurate alteration for all your material thickness from 0.5 – 4mm.
* This dial is designed so that a straightforward rotation clock or anti clockwise to achieve desired plate thickness.
* Measurement on dial indicates and refers to actual blade gap distance in millimetres.
* CONTROLLER ESTUN E21S.
* Control unit mounted on swivel pendant arm. Transfer balls inserted into work table allowing material to be easily moved.
| Weight | 3800 kg |
|---|---|
| Dimensions | 3.3 × 2.2 × 2.2 cm |
Description
| MODEL | BENZEL-6mm X 2500 |
|---|---|
| CONTROLLER | Estun E21-S with Invertor |
| SHEARING CAPACITY | 6mm Mild Steel |
| BLADE LENGTH | 2500mm |
| RAKE ANGLE VARIABLE | No |
| MAX RAKE ANGLE | No |
| MIN RAKE ANGLE | 1.5 Degree |
| NO HOLDDOWN | 09Pcs |
| OIL CAPACITY | 170 L |
| BACK GAUGE | 20mm To 900mm with Ball screw. |
| MOTOR | 7.5kw |
| LENGTH | 3100mm |
| WIDTH | 1750mm |
| HEIGHT | 1750mm |
| WEIGHT NETT/GROSS | 4,800 Kg |
| VOLUME | 15.972cm |
| PACKING SIZE L x W x H | 3300 x 2200 x 2200mm |
