DRILL: GEARED HEAD ZS-40APS AUTO 3PH
DRILL: GEARED HEAD ZS-40APS AUTO 3PH Excl. GST: $4,500.00
Incl. GST: $5,175.00
Back to products
DRILL: GEARED HEAD Z5040E MT4
DRILL: GEARED HEAD Z5040E MT4 Excl. GST: $4,999.00
Incl. GST: $5,748.85
DRILL: GEARED HEAD Z5028 MT3 3 PHASE 400V - Image 1
Click to enlarge

DRILL: GEARED HEAD Z5028 MT3 3 PHASE 400V

Excl. GST: $3,800.00
Incl. GST: $4,370.00

* Geared head MT4 drill.
* Comes with coolant pump and stand alone tank.
* Rise and fall table with 360° rotation and +/- 90° tilt.
* Fitted with tapping switch.
* Comes with machine light and emergency switch.

Weight 250 kg
Dimensions 0.73 × 0.39 × 2.1 cm

In stock

Add to compare
Add to wishlist
SKU: DMC359170 Category:
Description
Drill Capacity (mm) 28 mm
Tap Capacity (M) M18
Table Size (mm) 380 x 380 mm
Speeds (no.) 12 (75 to 3200) rpm
Speed Range (rpm) 75 – 3200
Spindle Taper MT3
DISTANCE SPINDLE TO COLUMN 250mm
Quill Stroke (mm) 130mm
DIMENSION OF BASE 535 x 360 mm
DISTANCE SPINDLE TO BASE 1220 mm
Motor (kW) 1.1 KW
Voltage (V) 415
Weight Nett / Gross (kg) 210 / 250
Volume (m³) 0.5979
Packing Size L x W x H (mm) 730 x 390 x 2,100
3610
Shipping & Delivery

Related products

Add to compare

DRILL: GEARED HEAD GHD-T25A 3PH

SKU: DMC348942
Excl. GST: $3,350.00
Incl. GST: $3,852.50
* Adjustable depth stop. * 2 speed forward & reverse. * Auto drill ejector. * Conveniently positioned emergency stop switch. * Rack & pinion adjustable table & spindle head. * Slotted table for workpiecs holddown. * Column diameter is 100mm.
Add to wishlist
Add to cart
Quick view
Add to compare

DRILL: GEARED HEAD ZX40H MT4 3PH 12 SPEED

SKU: DMC359075
Excl. GST: $4,500.00
Incl. GST: $5,175.00
* 12 speed geared head drilling machine. * Comes with power feed to quill for auto drilling. * Tapping switch. * Adjustable depth stop. * Feed rate selector. * The compound table makes this a very versitile machine.
Add to wishlist
Add to cart
Quick view
Add to compare

DRILL: GEARED HEAD WDM30A MT4 3PH

SKU: DMC359079
Excl. GST: $3,600.00
Incl. GST: $4,140.00
* The WDM30A drilling machine with auto feed. * Heavy duty slotted base & table. * Adjustable depth stop. * Flexible worklight. * Tapping switch. * Coolant system.
Add to wishlist
Read more
Quick view
Back in Stock Soon
Add to compare

DRILL: GEARED HEAD WDM30B MT4 1PH

SKU: DMC359080
Excl. GST: $4,800.00
Incl. GST: $5,520.00
* The WDM30B drilling machine with auto feed. * Heavy duty slotted base & table. * Adjustable depth stop. * Flexible worklight. * Tapping switch.
Add to wishlist
Read more
Quick view
Add to compare

DRILL: GEARED HEAD JZB5032 MT4 1 PH

SKU: DMC359081
Excl. GST: $4,300.00
Incl. GST: $4,945.00
* Compact but powerful machine. * Coolant system. * Auto drill ejector. * Feed rate selector. * Reverse start switch.
Add to wishlist
Read more
Quick view
Add to compare

DRILL: GEARED HEAD ZS-40APS AUTO 3PH

SKU: DMC359152
Excl. GST: $4,500.00
Incl. GST: $5,175.00
* Heavy duty geared head drilling machine. * Tilting head and rotating table. * Heavy column and base to give this machine rigidity. * Good spindle travel. * Fitted with coolant system with fluid resevoir in the base of the machine. * Automatic feeding.
Add to wishlist
Read more
Quick view
Back in Stock Soon
Add to compare

DRILL: GEARED HEAD Z5032 MT4. 420 V Three Phase.

SKU: DMC359175
Excl. GST: $4,116.00
Incl. GST: $4,733.40
* Geared head MT4 drill. * Depth gauge. * Electro-magnetic feed. * Rise and fall table with 360° rotation and +/- 90° tilt. * Fitted with tapping switch. * Comes with machine light and emergency switch.
Add to wishlist
Read more
Quick view
Add to compare

DRILL: GEARED HEAD Z5050 MT4

SKU: DMC359195
Excl. GST: $9,999.00
Incl. GST: $11,498.85
* Heavy duty drilling machine for industrial use. * Equipped with power feed on the quill with 3 feed rates. * Feed is controlled by electromagnetic clutch. * Large rise and fall table with 360° rotation and +/- 90° tilt. * Fitted with tapping switch. * The electrical system has a short circuit and overload protection according to CE standard.
Add to wishlist
Add to cart
Quick view
