| DESCRIPTION | Rotary Table 4″ |
|---|---|
| TYPE | Tilting Rotary Table |
| HEIGHT HORIZONTAL | 55.0mm |
| HEIGHT VERTICAL | 105mm |
| T-SLOT SIZE | 8.0mm |
| WEIGHT NETT/GROSS | 3.80kg |
| VOLUME | 0.0175cm |
| PACKING SIZE L X W X H | 330 x 230 x 230mm |
Description
SKU : RT-9580002A
Price per Unit
$225.00 (Exc GST)
$258.75 (Inc GST)
FEATURES:
* This 4″ Tilting rotary table is a very versitile unit
* Tilting range is 0 – 90 Degrees with positive locking
* Table diameter is 100mm
* Worm gear ratio 1:36 = 1 rotation will increase by 10 degrees
* Graduated indexing dial to 360 derees
* Centre height in verticle = 66.0mm approx
Hand wheel is graduated in 10 min divisions and can be set at zero
* Comes with tee slots in table
* Can be bolted in verticle or horizontal position
| Weight | 3.8 kg |
|---|---|
| Dimensions | 0.33 × 0.23 × 0.23 cm |
Specifications
Description
Reviews (0)
Shipping & Delivery
