PRESS BRAKE: BENZEL PBCNC 110T X 3200MM-5C DELEM DA66T

* Hydraulic / Mechanical ram, synchronised positive stop design * Ram stroke controlled by precision mechanical nut depth stops built into each cylinder * Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability * Hardened ball screw on back gauge with manual crowning arrangement * Front support can be easily adjusted and moved depending on the sheet width * Hydraulic MPA pressure gauge mounted on right side of support frame * With quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness * Incorporating with hydraulic overload protection * Enclosed rear gate with micro safety switches complete with sliding rear door for easy access * Conveniently mounted control box on pendant for quick swivel and adjustments * Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.

* Strong welded steel structure Stress relieved to improve stability * Torsion shaft forced synchronisation of mechanical limit stopper balance * Intergrated hydraulic system can accomodate large range of speed regulation * Delem Touch screen Controller DA66T. * Akas (Germany) CE Laser guard * Front support moveable on guide rails * Quick clamping top tool. Bottom tool on guide rails * Segmented top and bottom tool.

* Strong welded steel structure Stress relieved to improve stability * Torsion shaft forced synchronisation of mechanical limit stopper balance * Intergrated hydraulic system can accomodate large range of speed regulation * Delem Touch screen Controller DA66T. * Akas (Germany) CE Laser guard * Front support moveable on guide rails * Quick clamping top tool. Bottom tool on guide rails * Segmented top and bottom tool.

* With Super Custom you can form even the biggest structures,with the highest speed and versatility. * 1300-mm daylight and 900-mm tool adapters * Bend boxes up to 600-mm deep * 400-mm stroke * Extract pieces easily * Active real-time crowning * Straight profiles with any material * 3D file import and 2D blank output * A bridge between design and other machinery * AirSlide sliding tool adapters and clamping * Quick and flexible tooling * ECO/ECO+ package * Increase speed and reduce consumption * GPS4 angle control * Accurate bends on the first try * Wireless foot pedal * No cables on the floor. * Assistance and connectivity * With our Service you're in good hands * Any tonnage and size up to 2500 tons/14 m and beyond * Custom daylights and strokes * Tailored around your needs * Industry 4.0 Ready * Data analysis and predictive maintenance
