PRESS BRAKE: 2 AXIS WC67Y-135T X 4200MM ESTUN E200P
$59,000.00
* Hydraulic / Mechanical ram, synchronised positive stop design, ram stroke controlled by precision mechanical nut depth stops built into each cylinder.
* Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability.
* Hardened ball screw on back gauge with manual crowning arrangement.
* Front support can be easily adjusted and moved depending on the sheet width.
* Hydraulic MPA pressure gauge mounted on right side of support frame with quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness, incorporating with hydraulic overload protection.
* Enclosed rear gate with micro safety switches complete with sliding rear door for easy access.
* Conveniently mounted control box on pendant for quick swivel and adjustments.
* Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.
Description
| MODEL | PBNC- 135 X 3200 |
|---|---|
| PRESSING FORCE | 135 Ton |
| BENDING LENGTH | 4000 mm |
| STROKE | 130 mm |
| MAX DAY LIGHT | 390 mm |
| BACKGAUGE TRAVEL | 600 mm |
| DISTANCE BETWEEN COLUMN | 3200 mm |
| THROAT DEPTH | 415 mm |
| APPROACH SPEED | 50 mm/Sec |
| PRESSING SPEED | 7.5 mm/Sec |
| RETURN SPEED | 45 mm/Sec |
| MOTOR POWER | 7.5 Kw / 10 HP |
| CONTROLLER TYPE | ESTUN E200P |
| OIL TANK CAPACITY | 300 L |
| WEIGHT NETT/GROSS | 10,350 Kg |
| VOLUME | 17.9400cm |
Shipping & Delivery
Related products
PRESS BRAKE: 2 AXIS ADH WC67E -63T X 2500MM ESTUN 200P
SKU:
PBK100080
* Hydraulic / Mechanical ram, synchronised positive stop design, ram stroke controlled by precision mechanical nut depth stops built into each cylinder.
* Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability.
* Hardened ball screw on back gauge with manual crowning arrangement.
* Front support can be easily adjusted and moved depending on the sheet width.
* Hydraulic MPA pressure gauge mounted on right side of support frame with quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness, incorporating with hydraulic overload protection.
* Enclosed rear gate with micro safety switches complete with sliding rear door for easy access.
* Conveniently mounted control box on pendant for quick swivel and adjustments.
* Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.
PRESS BRAKE: 2 AXIS ADH WC67E-160T X 4000MM ESTUN E200P
SKU:
PBK100102
* Hydraulic / Mechanical ram, synchronised positive stop design, ram stroke controlled by precision mechanical nut depth stops built into each cylinder
* Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability.
* Hardened ball screw on back gauge with manual crowning arrangement
* Front support can be easily adjusted and moved depending on the sheet width
* Hydraulic MPA pressure gauge mounted on right side of support frame with quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness, incorporating with hydraulic overload protection
* Enclosed rear gate with micro safety switches complete with sliding rear door for easy access
* Conveniently mounted control box on pendant for quick swivel and adjustments
* Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.
PRESS BRAKE: BENZEL PBCNC 63T X 2600MM-4C DELEM DA58T
SKU:
PBK100285
PRESS BRAKE: BENZEL PBCNC 125T X 3200MM-5C DELEM DA58T
SKU:
PBK100291
* Strong welded steel structure Stress relieved to improve stability
* Rexrorth Hydraulic propotional valves
* GIVI Italian Linear scales
* Schneider electrical components
* Parker Oil seals and Pump from USA
* Main motor Siemens
* Delem DA58T controller
* Akas laser safe system
* One set of Top and Bottom tool
* Front support on guide rails
* This machine is equiped with Hydraulic crowning.
PRESS BRAKE: BENZEL PBCNC 150T X 4100MM-5C DELEM DA66T
SKU:
PBK100293
* Strong welded steel structure Stress relieved to improve stability
* Torsion shaft forced synchronisation of mechanical limit stopper balance
* Intergrated hydraulic system can accomodate large range of speed regulation
* Delem Touch screen Controller DA66T.
* Akas (Germany) CE Laser guard
* Front support moveable on guide rails
* Quick clamping top tool. Bottom tool on guide rails
* Segmented top and bottom tool *
PRESS BRAKE: BENZEL PBCNC 160T X 3100MM-5C DELEM DA66T
SKU:
PBK100295
* Strong welded steel structure Stress relieved to improve stability
* Torsion shaft forced synchronisation of mechanical limit stopper balance
* Intergrated hydraulic system can accomodate large range of speed regulation
* Delem Touch screen Controller DA66T.
* Akas (Germany) CE Laser guard
* Front support moveable on guide rails
* Quick clamping top tool. Bottom tool on guide rails
* Segmented top and bottom tool.
PRESS BRAKE: BENZEL PBCNC 300T X 4100MM- 5C DELEM DA66T
SKU:
PBK100320
* Strong welded steel structure Stress relieved to improve stability
* Torsion shaft forced synchronisation of mechanical limit stopper balance
* Intergrated hydraulic system can accomodate large range of speed regulation
* Delem Touch screen Controller DA66T.
* Akas (Germany) CE Laser guard
* Front support moveable on guide rails
* Quick clamping top tool. Bottom tool on guide rails
* Segmented top and bottom tool.
PRESS BRAKE: BENZEL PBCNC 500TX 8200MM- 4C DELEM DA66T
SKU:
PBK100430
* Strong welded steel structure Stress relieved to improve stability
* Torsion shaft forced synchronisation of mechanical limit stopper balance
* Intergrated hydraulic system can accomodate large range of speed regulation
* Delem Touch screen Controller DA66T.
* Akas (Germany) CE Laser guard
* Front support moveable on guide rails
* Quick clamping top tool. Bottom tool on guide rails
* Segmented top and bottom tool
