PLANER: TANNER TP-304 600MM 3 SIDER SPIRAL HEADS
$0.00
* TANNER WT-760 Planer with 760mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 20hp main motor
* Power rise & fall
* Cutterblock with antikick-back guards
| Weight | 920 kg |
|---|---|
| Dimensions | 1.04 × 1.36 × 1.39 cm |
Description
| CUTTING WIDTH | 410mm |
|---|---|
| CUTTING HEIGHT | 12 – 200mm |
| MIN LENGTH | 300mm |
| MIN THICKNESS | 6.0mm |
| MAX DEPTH OF CUT | 4.0mm |
| TABLE AREA | 965 X 787mm |
| TABLE ROLLERS | 65.0mm |
| FEED SPEEDS | Variable |
| FEED RATE | 0-25m/min |
| CUTTERHEAD SPEED | 6500mm |
| CUTTERHEAD | Spiral Cutterhead |
| TCT TIPS | 15 X 15 X 2.5mm |
| MOTOR X TWO | 5.5kw – 4.0kw |
| WEIGHT NETT/GROSS | 850/920kg |
| VOLUME | 1.966cm |
| PACKING SIZE LX W X H | 1040 x 1260 x 1390mm |
| OVERALL DIMENTIONS | 1080 x 960 x 1382mm |
Shipping & Delivery
Related products
PLANER: 12″ MB103 1PH
SKU:
TKN112120
* This machine comes with a powerful 3hp single phase motor
* Equiped will Four knife cutterhead
* Serrated infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Fully enclosed carbinet stand
* Overhead rollers for passing workpiece over when re-machining
PLANER: TANNER TK-380 15″ M/UNDER 3HP 1PH
SKU:
TKN112124
* This machine comes with a powerful 3hp single phase motor
* Equiped will three knife cutterhead
* Serrated infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Fully enclosed carbinet stand
* Overhead rollers for passing workpiece over when re-machining
PLANER: TANNER 16″ 2.5HP 1PH MOTOR UNDER
SKU:
TKN112610
* This Tanner 16: Planer comes with a 2.5hp single phase motor
* Equiped wilh three knife 72.0mm cutterhead
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Fully enclosed carbinet stand
* Overhead rollers for passing workpiece over when re-machining
PLANER: TANNER 16″ 2.2KW 1PH MOTOR UNDER
SKU:
TKN112618
* This Tanner TP-1040F 16" Planer comes with a 2.2kw motor
* Equiped wilh 3 blade cutter head
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Fully enclosed carbnet stand
PLANER: TANNER TH410A 16″ 3HP 1PH INDUSTRIAL S/HEAD
SKU:
TKN112620
* This Tanner 16: Industrial Planer comes with a 3.0hp single phase motor
* Equiped wilh three knife 72.0mm cutterhead
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Heavy cast iron table
* Top mounted dust chute
PLANER: TANNER WT-760 760MM 20HP SPIRAL HEAD
SKU:
TKN114340
* TANNER WT-760 Planer with 760mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 20hp main motor
* Power rise & fall
* Cutterblock with antikick-back guards
PLANER: TANNER FOUR SIDER 300MM 7.5HP
SKU:
TKN115020
* TANNER M-412 side Planer
* Industrial quality machine with table surface of high ductile cast iron
* Cutterhead guard is manufactured from HSS, heat treated
* Numerical control panel allows sizing adjustment of cutters for convenience and rapit settings
* Fitted with overload protection
* Feeding can be opperated in jog mode for accurate settings
Three phase motor drive.
Powerful motor drive for each spindle.
Digital position control for accurate and easy setting.
7,000 rpm high spindle speed.
Compact construction. Maximum stability.
Variable feed speed.
See-thru top guard.
PLANER: TANNER FOUR SIDER 300MM 20HP H/DUTY
SKU:
TKN115030
* TANNER SKD-300/6 side Planer
* Industrial quality machine with table surface of high ductile cast iron
* Cutterhead guard is manufactured from HSS, heat treated
* Numerical control panel allows sizing adjustment of cutters for convenience and rapit settings
* Fitted with overload protection
* Feeding can be opperated in jog mode for accurate settings
Three phase motor drive.
Powerful motor drive for each spindle.
Digital position control for accurate and easy setting.
6,000 rpm high spindle speed.
Compact construction. Maximum stability.
Variable feed speed.
See-thru top guard.
* Powerful 20hp motors top & bottom
