PLANER: TANNER TP-206 600MM 2 SIDER SPIRAL HEADS
$13,600.00
* TANNER TP206 Planer with 760mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Power rise & fall
* Cutterblock with antikick-back guards
| Weight | 920 kg |
|---|---|
| Dimensions | 1.04 × 1.36 × 1.39 cm |
Description
| CUTTING WIDTH | 600mm |
|---|---|
| CUTTING HEIGHT | 12 – 200mm |
| MIN LENGTH | 300mm |
| MIN THICKNESS | 6.0mm |
| MAX DEPTH OF CUT | Up 4.0mm – Down 3.0mm |
| TABLE AREA | 965 X 787mm |
| TABLE ROLLERS | 65.0mm |
| FEED SPEEDS | Variable |
| FEED RATE | 8-11m/min |
| CUTTERHEAD SPEED | 6500mm |
| CUTTERHEAD | Spiral Cutterhead |
| TCT TIPS | 15 X 15 X 2.5mm |
| MOTOR X TWO | Top 5.5kw – Bottom 4.0kw |
| WEIGHT NETT/GROSS | 850/920kg |
| VOLUME | 1.966cm |
| PACKING SIZE LX W X H | 1040 x 1260 x 1390mm |
| OVERALL DIMENTIONS | 1080 x 960 x 1382mm |
