MULTI HEAD: 4-SPINDLE 78.0-206MM LONG GER 4C-T16 - Image 1
Click to enlarge

MULTI HEAD: 4-SPINDLE 78.0-206MM LONG GER 4C-T16

Excl. GST: $3,630.00
Incl. GST: $4,174.50

* Multiple adjustable drilling head with minimal effort when changing centres
* Suitable for drilling and tapping
* Reversable
* Graduated for ease of setting
* Drill capacity 1.0 – 14.0mm
* Flange mount to machine
* Drive taper option: MT2,3,4
* Other configerations available on request

Weight 22 kg
Dimensions 0.22 × 0.2 × 0.2 cm
PLEASE ENQUIRE
Add to compare
Add to wishlist
SKU: MSH300420 Category:
Description
DESCRIPTION 4 Spindle (Circular) Drill
MODEL 4C-T16
DRILLING CAPACITY 14.0mm
SPINDLES 4 ( Circular)
RANGE 78 – 206mm
HEAD MOUNT Dog Drive
DRILL MOUNT Collets
WEIGHT NETT/GROSS 21.7/22.0kg
VOLUME 0.0088cm
