MILLING VICE: 150MM MODULAR PULL DOWN JAWS HARLINGEN
$1,295.00
* High precision modular Milling Vice by Harlingen
* Accuracy to 0.005mm/100mm
* Manufactured from high alloy resitance steel
* All Harlingen vices and accessories are modular and interchangeable
* Perfect alignment is achieved to provide different workholding solutions
* Vices can be matched side to side with highest precision and minimal set up times
* Max jaw opening on this model is 300mm
| Weight | 36 kg |
|---|---|
| Dimensions | 0.6 × 0.25 × 0.22 cm |
In stock
Description
| DESCRIPTION | Modular Milling Vice |
|---|---|
| JAW WIDTH | 150mm |
| JAW OPENING | 300mm |
| JAW HEIGHT | 50.0mm |
| JAW TYPE | Pull Down |
| LENGTH O/A | 510mm |
| MATERIAL | Alloy Steel |
| PARALLELISM | 0.005mm/100mm |
| SQUARENESS | 0.005mm |
| BODY HARDNESS | HRC-60 |
| BASE | Fixed |
| PACKING | Wooden Box |
| WEIGHT NETT/GROSS | 36kg |
| VOLUME | 0.0330cm |
