CLAMPING STUD: M16 X 2.0TPI X 100MM
Excl. GST: $9.70
Incl. GST: $11.16
Incl. GST: $11.16
MILLING MACHINE: MDH50B NT40 1PH VM
Excl. GST: $11,600.00
Incl. GST: $13,340.00
Incl. GST: $13,340.00
MILLING MACHINE: GLOBAL WM20 1PH
Excl. GST: $13,000.00
Incl. GST: $14,950.00
* This is a small turret type milling machine with R-8 taper and single phase motor
* Large diameter quill which is chromed for durability
* Head can be tilted left and right
* Overarm can move backwards and forward and swivel 360deg
* Ideal machine for small workshop or home workshop
| Weight | 800 kg |
|---|
Description
| Table Size (mm) | 226 x 910 |
|---|---|
| Travel X-axis (mm) | 580 |
| Travel Y-axis (mm) | 240 |
| Travel Z-axis (mm) | 350 |
| Quill Stroke (mm) | 127 |
| Quill Diameter (mm) | 90 |
| Spindle Taper | R8 |
| Speeds (no.) | 5 |
| Speed Range (rpm) | 240 – 1480 |
| Max Nose to Table (mm) | 340 |
| Max Nose to Column (mm) | 280 |
| Motor (kW) | 1.125 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 750 / 800 |
| Volume (m³) | 2.73 |
| Packing Dimensions L x W x H |
Shipping & Delivery
Related products
MILLING MACHINE: X6325A /TM240 TURRET NT30 1PH (B/SCREWS)
SKU:
MM-228509
* The TM-240 (X6323B) is a turret style milling machine.
* Head is fully tiliting, swivelling & rotating
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle
* Variable speed from 65-4500rpm
* Double 55° dovetail guide way is adopted on both Y and Z axis.
* One shot lubrication
* Fitted with precision ball screws for utmost accuracy
* Comes with power rise and fall on X axis
* X & Y axis are fitted with aglin power feeds (Taiwan)
Digital 3 axis readout is Sino brand
MILLING MACHINE: M6325A/ TM240 TURRET R8 TAPER
SKU:
MM-228514
* The TM-240A (X6325A) is a turret style milling machine.
* Fully tiliting, swivelling & rotating head.
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle.
* Double 55° dovetail guide way is adopted on both Y and Z axis.
* One shot lubrication.
MILLING MACHINE: TM270 TURRET NT40 (BALL SCREWS)
SKU:
MM-228616
* The TM-270 (X6325A) is a turret style milling machine.
* Head is fully tiliting, swivelling & rotating
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle
* Variable speed from 65-4500rpm
* Double 55° dovetail guide way is adopted on both Y and Z axis.
* One shot lubrication
* Fitted with precision ball screws for utmost accuracy
* Comes with power rise and fall on X axis
* X & Y axis are fitted with aglin power feeds (Taiwan)
Digital 3 axis readout is Sino brand
MILLING MACHINE: TM330 TURRET (M6333) NT40
SKU:
MM-228620
* The TM-330 (M6333) is a turret style milling machine.
* Fully tiliting, swivelling & rotating head.
* The saddle guideways are lined with turcite wearable material.
* Hardened & precision ground work table and guideways.
* High quality meehanite cast body.
* Chromed and ground spindle.
* 3 axis digital readout & X/Y axes powerfeed.
* Powered rise & fall of the milling table.
* Automted lubrication system.
* NT40 spindle taper for heavy milling operations.
* Power drawbar fitted.
MILLING MACHINE: 6H 1372 X 254MM TABLE TURRET TAIWAN
SKU:
MM-244136
* The 6H model comes with standard 1372mm table length.
* Table is hardened and ground for durability and long service life.
* Powerful 5hp motor.
* Large diameter quill (105mm) for rigid milling performance.
* Y-Z axis rubber way cover.
* Auto lubrication system.
* Electrical cabinet.
* Made in Taiwan.
MILLING MACHINE: 4VS 1370 X 254MM TABLE TURRET TAIWAN
SKU:
MM-244242
* The 4VS model turret milling machine comes with two table options - 1270 & 1370mm.
* Table and guideways are hardened and precision ground.
* Y-Z axis have rubber way cover for protection.
* Auto lubrication system.
* Electrical cabinet.
* One shot lubrication system.
* Ways are X & Y are Tercite B coated.
* Fitted with power feed on X travel.
* Made in Taiwan.
MILLING MACHINE: V2 1224 X 228MM TABLE NT40 1PH TURRET
SKU:
MM-244300
* This 2V model is the smallest of the Turret milling machines made in China
* Fitted with Tawann milling head which icorperates P5 spindle bearings
Comes with E-GEO lead screws for utmost accuracy
* Fitted with 2 axis DRO
* Comes as a manual machine but you can add power feeds etc onto it
* Y-Z axes rubber way covers.
* Auto lubrication system.
* Electrical cabinet
* Shindle taper is NT40
Overhead pentant control panel for convenient
MILLING MACHINE: V4 1370 X 254MM TABLE NT40 1PH TURRET
SKU:
MM-244308
* This 4V model is the smallest of the Turret milling machines made in China
* Fitted with Tawann milling head which icorperates P5 spindle bearings
Comes with E-GEO lead screws for utmost accuracy
* Spindle bore is NT40
* Fitted with 2 axis DRO
*power feed on X axis
* Y-Z axes rubber way covers.
* Auto lubrication system
* Slideways with Tercite-B coating
* Coolant system
* Electrical cabinet
Overhead pendant control panel for conveinence
* This model is machined with square ways
