MILLING MACHINE: BED TYPE 1524 X 305MM TABLE NT40
$117,531.46
* Heavy duty bed type milling machine.
* Fully hardened and ground gears, shafts, table, slideways, and leadscrews.
* Y & Z axes rubber way covers
* Auto lubrication system
* Electrical cabinet.
| Weight | 1.9 kg |
|---|
Description
| Table Size (mm) | 1524 x 305 |
|---|---|
| Travel X-axis (mm) | 1000 |
| Travel Y-axis (mm) | 480 |
| Travel Z-axis (mm) | 560 |
| Quill Stroke (mm) | 127 |
| Quill Diameter (mm) | 100 |
| Spindle Taper | NT40 |
| Speed Range (rpm) | 70 – 4200 |
| Max Nose to Table (mm) | 660 |
| Max Nose to Column (mm) | 420 |
| Motor (kW) | 3.75 |
| Voltage (V) | 415 |
| Weight (kg) | 1,900 |
| Volume | |
| Packing Dimensions L x W x H |
