MAG/DRILL: MACKMA M50RLX- 50MM CAPACITY
$2,900.00
M50 RLX magnetic drilling machine, versatile in a compact form. The exchangeable MT 2 makes this magnetic drilling machine all all- round machine for drilling purposes. The variable speed and right / left option enable this magnetic drilling machine to also be used for tapping / threading up to M16, reaming and countersinking. This machine is supplied as standard with auto coolant system cleverly placed on top of the machine. The magnetic drilling machine is powered by a strong 1150 watts Eibenstock motor.
| Weight | 12.6 kg |
|---|---|
| Dimensions | 0.6 × 0.35 × 0.26 cm |
In stock
Description
| Brand | Mackma |
|---|---|
| Model | M-50RLX |
| Cap. Annular Cutters (mm) | 50 |
| Cap. Twist Drills (mm) | 23 |
| Cap. Countersinking (mm) | 40 |
| Cap. Reaming (mm) | 23 |
| Cap. Tapping (M) | M16 |
| Stroke (mm) | 75 |
| Weight (kg) | 22 |
| Magnetic Force (kg) | 3,265 |
| Speeds (rpm) | 50 – 450 |
| Spindle | MT 2 / 19mm Weldon |
| Voltage (V) | 240 |
| Motor Power (kW) | 1.1 |
| Weight Nett/Gross | 12.60kg |
| Volume | 0.0546cm |
| Packing Size L x W x H | 600 x 340 x 260mm |
Shipping & Delivery
Related products
MAG/DRILL: EUROBOOR ECO-30-30MM CAPACITY
SKU:
DSM360402
* Euorbor ECO-30- Magnetic Drilling system with a 900W motor to cope with the heaviest of work.
* At 8.5kg it is extremely light & very compact.
* The drilling system features a complete coolant system and roller bearing arbor.
* Easily mounts twist drills up to 13mm diameter.
* The Euroboor ECO.30 is the lightest ø 30 mm machine in the market *
Due to its small size the Euroboor ECO.30 is the ideal magnetic core drilling machine to drill holes in tight and narrow spaces
* This machine measures barely 27.5 cm in length
* With a power of 900 W this small ECO.30 magnetic core drilling machine cuts holes in metal easily and quickly
* Comes with 12 month warranty.
MAG/DRILL: EUROBOOR ECO-32-32MM CAPACITY
SKU:
DSM360404
* Euorboor ECO-32- Magnetic Drilling system with 1000W motor to cope with the heaviest of work.
* At 12.6kg it is lightweight and compact.
* The drilling system features a complete coolant system and roller bearing arbor support.
* Easily mounts weldon twist drills up to 13mm diameter and countersiks to 40mm
* This light and reliable machine is a true addition for every workplace
* Comes with 12 month warranty.
.
MAG/DRILL: EUROBOOR ECO-36 LOW PROFILE 36MM CAPACITY
SKU:
DSM360408
* The Euroboor ECO.36+ magnetic core drilling machine is the lowest drilling machine in the market, measuring only 6 1/2” (165 mm) height
* This magnetic core drilling machine is perfect for drilling in spaces with limited heights such as H-beams, steel structures, plates, profiles, etc
* The portable ECO.36+ is equipped with a powerful magnet, user friendly Quick Connect cutter fitment system, and easy release / lock feed handle for both left and right operation
* The drilling system features a coolant system and roller bearing arbor support.
* Comes with a 12 month warranty
MAG/DRILL: EUROBOOR ECO-40S 40MM CAPCITY LIGHTWEIGHT
SKU:
DSM360409
* Euorboor ECO-40S Magnetic Drilling system with a powerful 1.15kW motor to cope with the heaviest of work.
* At 10.3kg it is the lightest machine on the market.
* High efficiency motor with less heath generation.
* High accuracy capstan hub.
* Direct spindle drive.
* Integrated tool cooling and lubrication.
* Strong dual coil CNC machined magnet.
* Comes with 12 month warranty.
MAG/DRILL: EUROBOOR ECO-50S 50MM CAPACITY
SKU:
DSM360410
* Euorboor ECO-50S Magnetic Drilling system with 1.25kW motor to cope with the heaviest of work.
* Lightweight and compact unit only 11.2 Kg.
* Morse Taper 3 Spindle.
* The drilling system features a complete coolant system and roller bearing arbor support.
* 2 Speed Integrated oil bath gearbox
* High precision slide & rail construction..
* Comes with 12 month warranty
MAG/DRILL: EUROBOOR ECO-55-TA 55MM CAPACITY
SKU:
DSM360432
* Euorbor ECO-55-A Magnetic Drilling system with 1.7kW motor to cope with the heaviest of work.
* The automatic drilling system runs on high precision slide and rail construction with a complete coolant system and roller bearing arbor support.
* This model features LED load indicator with oil bath gearbox.
* Spindle is MT3.
* Comes with 12 month warranty.
MAG/DRILL: EUROBOOR ECO-80/4 80MM CAPACITY
SKU:
DSM360433
* Euorbor ECO-80/4 Magnetic Drilling system with 1.8kW motor to cope with the heaviest of work.
* The automatic drilling system runs on high precision slide and rail construction with a complete coolant system and roller bearing arbor support.
* Very long stroke.
* Spindle is MT3.
* Comes with 12 month warranty.
