| Swing Over Bed (mm) | 330 |
|---|---|
| Swing Over X-slide (mm) | 198 |
| Swing Over Gap (mm) | 450 |
| Between Centres (mm) | 1,000 |
| Bed Width (mm) | 187 |
| Spindle Nose | D1 -5 |
| Speeds (no.) | Variable |
| Speed Range (rpm) | 90 – 2,000 |
| Spindle Bore (mm) | 51 |
| Spindle Taper | MT6 |
| Metric Threading (M) | 0.45 – 10.0 |
| Imperial Threading (tpi) | 40 – 2-1/4 |
| Tailstock Taper | MT3 |
| Tool Height (mm) | 16 |
| Motor (kW) | 1.5 |
| Voltage (V) | 240 |
| Weight Nett / Gross (kg) | 580 / 600 |
| Volume (m³) | 2.24 |
| Packing Size L x W x H (mm) |
Description
SKU : L--120000
Price per Unit
$10,500.00 (Exc GST)
$12,075.00 (Inc GST)
FEATURES:
* The WM-330BV is variable speed with frequency inverter.
* The D1-5 spindle comes with a 51.0mm bore.
* Comes with gap bed for those larger diameter workpieces.
* Automatic feed and thrading are fully interlocked.
* Inductioned hardened and precision ground V bedways.
* Hardened and precision ground headstock gears.
* Fitted with independent leadscrew and feed shaft
