LATHE: EL300 300 X 750 X 38MM BORE ELOTRONIC 1PH V/S
$9,900.00
* Induction hardened & precision ground V-way beds.
* Spindle supported by high quality taper roller bearings
* Large range of speeds and dial up thread cutting options
* Quickchange toolpost for speedy tool changing
* Confrol screen with fully fuctioning to drive this lathe
* Can be used as manual lathe or auto threading
Special roller stand with leveling screws & locking screws
| Weight | 600 kg |
|---|
Description
| Swing Over Bed (mm) | 300 |
|---|---|
| Swing Over X-slide (mm) | 224 |
| Swing Ctoss Slide (mm) | 190 |
| Between Centres (mm) | 1,000 |
| Bed Width (mm) | 187 |
| Spindle Nose | D1-4 |
| Speeds (no.) | Variable |
| Speed Range (rpm) | 50 – 2,000 |
| Spindle Bore (mm) | 38 |
| Spindle Taper | MT5 |
| Metric Threading (M) | 0.25 – 4.0 |
| Imperial Threading (tpi) | 6 – 80 |
| Tailstock Taper | MT3 |
| Tool Height (mm) | 16 |
| Motor (kW) | 1.5 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 600 / 700 |
| Volume (m³) | 2.1353 |
| Packing Size L x W x H (mm) | 1,940 x 750 x 1,500 |
Shipping & Delivery
Related products
LATHE: LD-1440E 360 X 1000MM 3PH WITH DRO QCT (TAIWAN)
SKU:
L--109310
* Induction hardened & precision ground V-way beds.
* Hardened & ground headstock gears.
* Cast from quality high tensile cast iron.
* Sino 2 axis digital readout.
* Coolant pump & tank system.
* Fitted with a work lamp & foot brake for added safety.
* Quickchange toolpost for speedy tool changing.
* Dual graduation thread dial.
* Gap bed for larger diameter work pieces.
* Manufactured in Taiwan.
LATHE: GLH-330 330 X 1000 X 38MM 1 PHASE (NEW)
SKU:
L--120470H
* New Model
* Precision ground and supersonic frequency hardened bedways.
* The spindle is supported with precision roller bearings.
* Head stock gears are made of high quality steel ground and hardened.
* Sealed and easy operating feed box has various feeds and thread cutting functions.
* ASA D1-4 camlock spindle nose.
* Machine is fitted with foot brake & work lamp for extra safety.
* Short bed length and space saving for training institutions.
* Fitted with safety chuck guard.
* Emergency stop buttons both ends of chip tray
LATHE: L-320/CQ9332 320 X 600 X 38MM BORE, 1 PHASE
SKU:
L--120502
LATHE: BL-336D 300 X 900 X 38MM BORE DRO, 1 PHASE
SKU:
L--120513
* Induction hardened & precision ground V-way beds.
* D1-4 Spindle is supported by high quality taper rolling bearing
* Automatic feed and threading are fully interlocked.
* Coolant pump & tank system.
* Fitted with a work lamp & foot brake for added safety.
* Quickchange toolpost for speedy tool changing.
* Gap bed for larger diameter work pieces.
* Independent leadscrew & feed rod.
* Carriage mounted spindle control lever.
* Tailstock can be offset for turning tapers.
LATHE: WBL-835 180 X 350 X 20MM BORE V/SPEED 1 PHASE
SKU:
L--165150
* Variable speed control board offering a wide range of speeds without gear change.
* The bedways are hardened and ground for lasting accuracy and durability.
* Adjustable gibs on slideways.
* Tailstock can be offset for taper turning.
* Fitted with reverse switch for added versatility.
* Equipped with emergency stop button for added safety.
* Ideal hobby lathe - easy to opperate - easy to store.
* Stand is sold seperately.
LATHE: WM-250AF 250 X 700 X 26MM BORE (NEW MODEL) 1 PH
SKU:
L--165264
* New model, one of our most popular lathes with new modifications and a longer bed.
* Induction hardened & precision ground V-way beds.
* Power cross slide and longitudinal feed.
* Tailstocks can be offset for turning tapers.
* Stand alone coolant pump & tank system.
* Handy LED lamp located in the middle of splashguard.
* Includes change gears for metric & imperial threading.
* Righthand & lefthand thread cutting is available.
* Spindle supported by high precision bearings.
* Adjustable gibs for slideways.
* Stand is sold seperately.
LATHE: WM-250V 250 X 750 X 26MM BORE V/SPEED 1 PHASE
SKU:
L--165270
* V-way bed is hardened & precision ground.
* Spindle is supported by a precision tapered roller bearing.
* MT3 spindle taper gets more capacity.
* Powered longitudinal feed for threading.
* Adjustable gibs for slideways.
* Right land & left hand thread cutting is available.
* Tailstock can be offset for taper turning.
* Equipped with high quality gearbox belt & control board.
* Stand is sold seperately.
LATHE: SHOPTURN-280G 280 X 650 X 26MM BORE G/HEAD 1 PHASE
SKU:
L--165278
* Compact lgeared Head Lathe with 12 speed precision ground gears
* Induction hardened & precision ground bedways.
* Headstock is gear driven in oil bath.
* Forward/reverse & emergency stop switches.
* Tailstock can be offset for turning tapers.
* Covered leadscrews & limit switches for safety.
* Metric & imperial threading dial indicator.
* Extra wide bedway for more capacity.
* Ideal for hobbyists and small workshops.
* Stand is sold seperately.
