HYDRAULIC TELESCOPIC CYLINDER: 10 TON MAX LIFT 435MM
$895.00
* This telescopic hydraulic cylinder is ideal when there is mimium clearance and a very high lift is required
* Manufactured from high strength alloy steel for durability
* Baked enamal finish to increase corrosion resistance
* Plunger wiper reduces contamination , extending cylinder life
* Matching pump – HHB-700A
| Weight | 40 kg |
|---|---|
| Dimensions | 0.23 × 0.23 × 0.35 cm |
In stock
Description
| DESCRIPTION | Hyd Telescopic Cylinder |
|---|---|
| CAPACITY | 10 Ton |
| MIN HEIGHT | 280mm |
| MAX HEIGHT | 435mm |
| STROKE | 155mm |
| BASE SIZE | 110mm Dia |
| LIFTING STAGES | Two Stage |
| RECOMENDED PUMP | HHB-700 |
| CONNECTOR | HH-ll R2 Male Half Coupler |
| WEIGHT NETT/GROSS | 40/40kg |
| VOLUME | 0.0185cm |
| PACKING SIZE | 230 X 230 X 350mm |
