DRILL PRESS: KTK TB-120 1PH AUTO FEED
$2,300.00
* The KTK range of Industrial machines are designed for the industrial user
* This is a bench model and features auto feed on the quill.
* Industrial quality machines which are rugged and reliable and are designed for allworkshop conditions.
* Comes with MT2 quill taper (We can supply MT2 x 19mm arbor capable of holding annular cutters up to 50mm).
* Also capable of running multi-spindle heads for production enviroment.
* These machines are manufactured in Taiwan and are top quality industrial machines and will offer many years of trouble free service.
| Weight | 110 kg |
|---|---|
| Dimensions | 0.4 × 0.74 × 1.3 cm |
Description
| Capacity (mm) | 16 |
|---|---|
| Table Size (mm) | 300 x 300 |
| Speeds (no.) | 9 |
| Speed Range (rpm) | 190 – 2600 |
| Spindle Taper | MT2 |
| Quill Diameter (mm) | 46 |
| Quill Stroke (mm) | 100 |
| Swing (mm) | 360 |
| Column Diameter (mm) | 80 |
| Table Slot (mm) | 16 |
| Motor (kW) | 0.75 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 100 / 110 |
| Volume (m3) | 0.3848 |
| Packing Size L x W x H (mm) | 400 x 740 x 1,300 |
