DIVIDING PLATES: FOR TSK-10″

* This 4" Tilting rotary table is a very versitile unit * Tilting range is 0 - 90 Degrees with positive locking * Table diameter is 100mm * Worm gear ratio 1:36 = 1 rotation will increase by 10 degrees * Graduated indexing dial to 360 derees * Centre height in verticle = 66.0mm approx Hand wheel is graduated in 10 min divisions and can be set at zero * Comes with tee slots in table * Can be bolted in verticle or horizontal position

* Table is made from high density Meehanite casting with ground finish * Tested by Heidenhain electronic testing equipment to ensure the utmost quality * Spindle end is supported by taper roller bearings to ensure stablity under cutting conditions * Worm is hardened and ground and has a ratio of 90:1 * The worktable is graduated to the full 360ø so that one turn of the handle moves the table through 4ø * Micro collar is graduated in steps of 1'min and vernier scale makes settings down to 10 seconds possible * These rotary tables are popular for their excellent performance practical design and affordable cost * Widely used for circular cutting work angle setting boring

* Fits Vertex 8 rotary table by removing handwheel *

* This Tailstock is suitable for the Vertex HV-14 Rotary Tables * Also suitable for other indexing fixtures *
